| Težina | 0,76 kg |
|---|---|
| Dimenzije | 26,5 × 26 × 5,5 cm |
| Tip | Matična ploča |
| Brand | MSI |
| Datum ažuriranja | 2025-03-25 21:36:00 |
| Broj povratnih naknada | 0 |
| PCIe x4 | n/a |
| PCIe x8 | n/a |
| Max. memorije [GB] | 64 |
| DVI | 1 |
| HDMI | 1 |
| 8-pin ATX 12V Power | n/a |
| 24-pin ATX Power | Y |
| PCI-X | n/a |
| Display Port | n/a |
| USB 3.0 | 2 |
| SATA3 | 4 |
| Podrška za integrirani grafičk | Y |
| WLAN connector | n/a |
| PCIe 3.0 x16 | 1 |
| SATA Express | n/a |
| M.2 | 1 |
| CPU | AMD Ryzen 3, AMD Ryzen 5, AMD Ryzen 7 |
| Socket | AM4 |
| Chipset (N) | AMD A520 |
| BUS[MHz] | 1600 |
| Broj utora | 2 |
| Model | A520M-A PRO |
| Šifra dijela | 911-7C96-001 |
| Jamstvo | 36 |
| Računalna komponenta | 0 |
| Memorija | DDR4 |
| Takt memorije [MHz] | 2933, 3200, 3466, 3600 |
| 20-pin ATX Power | Y |
| SATA II | n/a |
| RAID | 0, 1 |
| Mreža | 1x 10/100/1000 Ethernet |
| Parallel | n/a |
| Serial | n/a |
| PS/2 mouse | 1 |
| USB 3.1 | 1 |
| PS/2 keyboard | 1 |
| D-sub | n/a |
| AGP 4x/8x | n/a |
| Audio | 8-kanalni audio |
| USB 2.0 | 2 |
| S/PDIF Out | n/a |
| RJ45 | 1 |
| U.2 | n/a |
| 4-pin ATX 12V Power | 1 |
| Front panel audio | n/a |
| Chasis Intrusion | n/a |
| CD Audio In | n/a |
| CPU Fan Power | 1 |
| Chasis Fan Power | 1 |
| Format ploče | mATX |
| USB 3.2 | 4 |
| PCI | n/a |
| PCIe x16 | n/a |
| PCIe x1 | 1 |
| PATA | n/a |
| PCIe 5.0 x16 | 0 |
